MEMS Differential Pressure Sensor Wafer with Pressure Range 0~±100kPa/500kP

•  Operating temperature range: -40℃~125℃

•  Pressure range: 0kPa~±100kPa/±500kPa

•  The accuracy and stability in the life cycle are better than 1%F.S.

•  Automotive-qualified IATF16949-certified process platform

•  Comply with RoHS & REACH and halogen-free requirements

•  Compiles with AEC-Q103 standard

•  Single chip size: 1.8mmx1.8mmx0.4mm


•  Automotive: VBS vacuum boosting system sensor, EGR system differential pressure detection, Crankcase ventilation pressure sensor

•  Industrial: pressure switch, negative pressure vacuum detection, gas flow monitoring

•  Medical: ventilator, sphygmomanometer, oxygen generator, anesthesia apparatus, biosafety cabinet

•  Home appliances: coffee machine, vacuum cleaner, water purifier, vacuum juicer, etc

•  Consumption: air mattress, massage chair, air pump etc.
